flume 是什么

flume 是分布式,可靠,高可用的日志采集传输系统。

可以采集文件,socket数据包等各种形式的数据源。

同时可以把采集到的数据下沉到 hdfs,hive,hbase,kafka等外部存储系统。

而且其配置简单,适用于各种日志采集场景。

flume 的相关概念

  1. agent 是一个采集传输数据的数据传递员角色。其内部有 source,channel,sink 三个部分组成

  2. source 数据的来源

  3. channel 数据内部的传输通道,有缓存功能

  4. sink 下沉地,数据传输的目的地 可以是下一级 agent 或者存储系统


使用

  1. 修改 flume-env.sh 里面的 JAVA_HOME

  2. 编写配置文件 flume-simple.conf

    # 官网给出的简单配置文件
    # a1 是代理的名字
    # r1 是 sources 的名字,
    # k1 是 sink 的名字
    # c1 是 channel 的名字
    a1.sources = r1
    a1.sinks = k1
    a1.channels = c1

    # source r1 是一个 netcat 类型的源,也就是大名鼎鼎的 nc
    a1.sources.r1.type = netcat
    a1.sources.r1.bind = localhost
    a1.sources.r1.port = 44444

    # sink 类型是 logger ,flume 使用 log4j 输出日志
    # 关于具体的日志输出可以在 conf/log4j.properties 中配置
    a1.sinks.k1.type = logger

    # channel 是
    a1.channels.c1.type = memory
    a1.channels.c1.capacity = 1000
    a1.channels.c1.transactionCapacity = 100

    # Bind the source and sink to the channel
    a1.sources.r1.channels = c1
    a1.sinks.k1.channel = c1
  3. 修改 conf/log4j.properties,下面是默认的 log4j 配置文件

    # 首先是几个自定义的参数,也可以做在 jvm 启动时通过 -Dxxx 指定
    # -Dflume.root.logger=DEBUG,console when launching flume.
    # flume.root.logger 的值最后会赋值给 rootLogger
    flume.root.logger=INFO,LOGFILE
    flume.log.dir=./logs
    flume.log.file=flume.log

    log4j.logger.org.apache.flume.lifecycle = INFO
    log4j.logger.org.jboss = WARN
    log4j.logger.org.mortbay = INFO
    log4j.logger.org.apache.avro.ipc.NettyTransceiver = WARN
    log4j.logger.org.apache.hadoop = INFO
    log4j.logger.org.apache.hadoop.hive = ERROR

    # rootLogger 的语法为log4j.rootLogger = [ level ] , appenderName, appenderName
    # [ level ] 是日志级别,一般只使用 ERROR、WARN、INFO、DEBUG 四个级别
    # appenderName 指定输出到哪里,可以指定多个
    # 是通过 log4j.appender.xxxx = yyyy 定义的
    log4j.rootLogger=${flume.root.logger}

    # 输出到文件
    log4j.appender.LOGFILE=org.apache.log4j.RollingFileAppender
    log4j.appender.LOGFILE.MaxFileSize=100MB
    log4j.appender.LOGFILE.MaxBackupIndex=10
    log4j.appender.LOGFILE.File=${flume.log.dir}/${flume.log.file}
    log4j.appender.LOGFILE.layout=org.apache.log4j.PatternLayout
    log4j.appender.LOGFILE.layout.ConversionPattern=%d{dd MMM yyyy HH:mm:ss,SSS} %-5p [%t] (%C.%M:%L) %x - %m%n

    #
    log4j.appender.DAILY=org.apache.log4j.rolling.RollingFileAppender
    log4j.appender.DAILY.rollingPolicy=org.apache.log4j.rolling.TimeBasedRollingPolicy
    log4j.appender.DAILY.rollingPolicy.ActiveFileName=${flume.log.dir}/${flume.log.file}
    log4j.appender.DAILY.rollingPolicy.FileNamePattern=${flume.log.dir}/${flume.log.file}.%d{yyyy-MM-dd}
    log4j.appender.DAILY.layout=org.apache.log4j.PatternLayout
    log4j.appender.DAILY.layout.ConversionPattern=%d{dd MMM yyyy HH:mm:ss,SSS} %-5p [%t] (%C.%M:%L) %x - %m%n

    # console
    log4j.appender.console=org.apache.log4j.ConsoleAppender
    log4j.appender.console.target=System.err
    log4j.appender.console.layout=org.apache.log4j.PatternLayout
    log4j.appender.console.layout.ConversionPattern=%d (%t) [%p - %l] %m%n
  4. 启动

    flume-ng agent --conf conf --conf-file ./conf/flume-simple.conf --name a1 -Dflume.root.logger=DEBUG,console -Dorg.apache.flume.log.printconfig=true -Dorg.apache.flume.log.rawdata=true

    --name 一定要与配置文件中的相同

flume 从zookeeper上加载配置文件

这是一个还在试验的特性,通过命令行命令使用

flume-ng agent –conf conf -z zkhost:2181,zkhost1:2181 -p /flume –name a1 -Dflume.root.logger=INFO,console

flume 可以把一个数据源输出到多个 channel 和 sink


多个 flume 的配置

# list the sources, sinks and channels in the agent
agent_foo.sources = avro-AppSrv-source1 exec-tail-source2
agent_foo.sinks = hdfs-Cluster1-sink1 avro-forward-sink2
agent_foo.channels = mem-channel-1 file-channel-2

# flow #1 configuration
agent_foo.sources.avro-AppSrv-source1.channels = mem-channel-1
agent_foo.sinks.hdfs-Cluster1-sink1.channel = mem-channel-1

# flow #2 configuration
agent_foo.sources.exec-tail-source2.channels = file-channel-2
agent_foo.sinks.avro-forward-sink2.channel = file-channel-2

flume可以通过下面几种机制收集日志

  1. Avro

    a1.sources.r1.type = avro
    a1.sources.r1.bind = 0.0.0.0
    a1.sources.r1.port = 4141
  2. Thrift

    a1.sources.r1.type = thrift
    a1.sources.r1.bind = 0.0.0.0
    a1.sources.r1.port = 4141
  3. Exec
    执行一段脚本收集日志,容易丢失数据

    a1.sources.r1.type = exec
    a1.sources.r1.command = tail -F /var/log/secure

    // or 指定使用的 shell
    a1.sources.tailsource-1.type = exec
    a1.sources.tailsource-1.shell = /bin/bash -c
    a1.sources.tailsource-1.command = for i in /path/*.txt; do cat $i; done
  4. Spooling Directory Source
    监视一个文件夹,当有新文件时进行采集,可靠,不容易丢失数据,如果服务停止,会记录发送到哪里,然后重启时继续发送。

    a1.sources.src-1.type = spooldir
    a1.sources.src-1.spoolDir = /var/log/apache/flumeSpool
    a1.sources.src-1.fileHeader = true

    // 还可以设置
    // deletePolicy  true 是不是在消费完删除日志文件
    // fileHeader 是不是在文件头中保存文件路径
    // includePattern 正则表达式
    // ignorePattern 正则表达式,忽略文件
    // consumeOrder oldest|youngest|random 消费规则
    // pollDelay 多长时间轮训一次文件夹
    // recursiveDirectorySearch false 是否监视子文件夹
    // maxBackoff 如果 channel 满了,等待的最大时间
    // batchSize 传输的文件块大小
    // inputCharset UTF-8
  5. Taildir Source
    这是一个正在试验的功能

  6. Kafka Source

    tier1.sources.source1.type = org.apache.flume.source.kafka.KafkaSource
    tier1.sources.source1.batchSize = 5000  // 每次写入 channel 的数据条数
    tier1.sources.source1.batchDurationMillis = 2000 // 每次写入channel 的间隔时间
    tier1.sources.source1.kafka.bootstrap.servers = localhost:9092
    tier1.sources.source1.kafka.topics = test1, test2
    tier1.sources.source1.kafka.consumer.group.id = custom.g.id  //消费者分组

    // 或者使用正则表达式订阅话题
    tier1.sources.source1.kafka.topics.regex = ^topic[0-9]$
  7. NetCat Source

    a1.sources.r1.type = netcat
    a1.sources.r1.bind = 0.0.0.0
    a1.sources.r1.port = 6666
  8. 其他 source

    Syslog TCP Source
    Multiport Syslog TCP Source
    Syslog UDP Source
    HTTP Source
    Stress Source
    Scribe Source

flume sink 类型

  1. HDFS Sink

    a1.sinks.k1.type = hdfs
    a1.sinks.k1.hdfs.path = hdfs://host/flume/events/%y-%m-%d/%H%M/%S
    a1.sinks.k1.hdfs.filePrefix = events-
    // 读时间进行舍入,会影响 %t 以外的所有转义符
    a1.sinks.k1.hdfs.round = true
    a1.sinks.k1.hdfs.roundValue = 10
    a1.sinks.k1.hdfs.roundUnit = minute

    参看这里能用的转义符

    hdfs.filePrefix    FlumeData  // 创建的文件前缀
    hdfs.fileSuffix  // 后缀
    hdfs.rollInterval // 多长时间滚动一次
    hdfs.rollSize  // 多少字节滚动一次
    hdfs.rollCount  //  多少次写入,滚动一次
    hdfs.idleTimeout    0    // 空闲多长时间后关闭文件,0是不关闭
    hdfs.fileType    SequenceFile(default)|DataStream|CompressedStream
    hdfs.round    false
    hdfs.roundValue    1
    hdfs.roundUnit
    serializer    TEXT
  2. Hive Sink

    a1.sinks.k1.type = hive
    a1.sinks.k1.hive.metastore = thrift://127.0.0.1:9083
    a1.sinks.k1.hive.database = logsdb
    a1.sinks.k1.hive.table = weblogs
    a1.sinks.k1.hive.partition = asia,%{country},%y-%m-%d-%H-%M
    a1.sinks.k1.useLocalTimeStamp = false
    a1.sinks.k1.round = true
    a1.sinks.k1.roundValue = 10
    a1.sinks.k1.roundUnit = minute
    a1.sinks.k1.serializer = DELIMITED
    a1.sinks.k1.serializer.delimiter = "\t"
    a1.sinks.k1.serializer.serdeSeparator = '\t'
    a1.sinks.k1.serializer.fieldnames =id,,msg
  3. Logger Sink

    a1.sinks.k1.type = logger
  4. Avro Sink

    a1.sinks.k1.type = avro
    a1.sinks.k1.hostname = 10.10.10.10
    a1.sinks.k1.port = 4545
  5. Thrift Sink

    a1.sinks.k1.type = thrift
    a1.sinks.k1.hostname = 10.10.10.10
    a1.sinks.k1.port = 4545
  6. File Roll Sink

    a1.sinks.k1.type = file_roll
    a1.sinks.k1.sink.directory = /var/log/flume
  7. HBaseSink

    a1.sinks.k1.type = hbase
    a1.sinks.k1.table = foo_table
    a1.sinks.k1.columnFamily = bar_cf
    a1.sinks.k1.serializer = org.apache.flume.sink.hbase.RegexHbaseEventSerializer
  8. AsyncHBaseSink

    a1.sinks.k1.type = asynchbase
    a1.sinks.k1.table = foo_table
    a1.sinks.k1.columnFamily = bar_cf
    a1.sinks.k1.serializer = org.apache.flume.sink.hbase.SimpleAsyncHbaseEventSerializer
  9. Kafka Sink

    a1.sinks.k1.type = org.apache.flume.sink.kafka.KafkaSink
    a1.sinks.k1.kafka.topic = mytopic
    a1.sinks.k1.kafka.bootstrap.servers = localhost:9092
    a1.sinks.k1.kafka.flumeBatchSize = 20
    a1.sinks.k1.kafka.producer.acks = 1
    a1.sinks.k1.kafka.producer.linger.ms = 1
    a1.sinks.ki.kafka.producer.compression.type = snappy

channel

  1. Memory Channel

    a1.channels.c1.type = memory
    a1.channels.c1.capacity = 10000
    a1.channels.c1.transactionCapacity = 10000
    a1.channels.c1.byteCapacityBufferPercentage = 20
    a1.channels.c1.byteCapacity = 800000
  2. JDBC Channel,好像不能连接 mysql

  3. Kafka Channel

    a1.channels.channel1.type = org.apache.flume.channel.kafka.KafkaChannel
    a1.channels.channel1.kafka.bootstrap.servers = kafka-1:9092,kafka-2:9092,kafka-3:9092
    a1.channels.channel1.kafka.topic = channel1
    a1.channels.channel1.kafka.consumer.group.id = flume-consumer
  4. File Channel

    a1.channels.c1.type = file
    // 存储检查点
    a1.channels.c1.checkpointDir = /mnt/flume/checkpoint
    a1.channels.c1.dataDirs = /mnt/flume/data

Channel Selectors

  1. Replicating Channel Selector

    a1.channels = c1 c2 c3
    a1.sources.r1.selector.type = replicating
    a1.sources.r1.channels = c1 c2 c3
    a1.sources.r1.selector.optional = c3

    c1,c2 写入失败会导致错误,c3 是复制通道,失败会忽略

  2. Multiplexing Channel Selector
    根据头不同进行通道选择

    a1.channels = c1 c2 c3 c4
    a1.sources.r1.selector.type = multiplexing
    a1.sources.r1.selector.header = state
    a1.sources.r1.selector.mapping.CZ = c1
    a1.sources.r1.selector.mapping.US = c2 c3
    a1.sources.r1.selector.default = c4

Sink Processors

我们使用 Sink groups 组合一组 sink, 然后可以指定 processor 进行不同策略的调度

// 定义组
a1.sinkgroups = g1
a1.sinkgroups.g1.sinks = k1 k2
// 调度策略
a1.sinkgroups.g1.processor.type = load_balance

Load balancing Sink Processor

processor.sinks
processor.type load_balance
processor.backoff    false
// 调度机制
processor.selector    round_robin|random|FQCN
processor.selector.maxTimeOut    30000

例子

node2 采集数据传递给 node1 , 然后 node1 下沉到 hdfs
描述

node1:
    name:a1
    source: r1 type avro
    sinks:
        k1 type logger
        k2 type hdfs
    channels:
        c1 type memory
        c2 type memory
node2:
    name:a1
    source: r1 type spooldir
    sink: k1 type memory
    channel: c1 type avro

node1 配置文件

// node1
# Name the components on this agent
a1.sources = r1
a1.sinks = k1 k2
a1.channels = c1 c2

# sources
a1.sources.r1.type = avro
a1.sources.r1.bind = 0.0.0.0
a1.sources.r1.port = 4141
a1.sources.r1.channels = c1 c2

# Describe the sink
a1.sinks.k1.type = logger
a1.sinks.k1.channel = c1

a1.sinks.k2.type = hdfs
a1.sinks.k2.hdfs.path = hdfs://acyouzi01:9000/flume/events/%y
a1.sinks.k2.hdfs.filePrefix = events-
a1.sinks.k2.channel = c2

# For all of the time related escape sequences, a header with the key “timestamp” must exist among the headers of the event (unless hdfs.useLocalTimeStamp is set to true)
a1.sinks.k2.hdfs.useLocalTimeStamp = true

# Use a channel which buffers events in memory
a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100

a1.channels.c2.type = memory
a1.channels.c2.capacity = 1000
a1.channels.c2.transactionCapacity = 100

node2 配置文件

// node2
# Name the components on this agent
a1.sources = r1
a1.sinks = k1
a1.channels = c1

# sources
a1.sources.r1.type = spooldir
a1.sources.r1.spoolDir = /root/test/
a1.sources.r1.fileHeader = true
a1.sources.r1.channels = c1

# Describe the sink
a1.sinks.k1.type = avro
a1.sinks.k1.hostname = acyouzi01
a1.sinks.k1.port = 4141
a1.sinks.k1.channel = c1

# Use a channel which buffers events in memory
a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100
